Environmental simulation chamber for vehicle fuel cell engine
Description
This lab can provide fuel cell engine with intake gas and simulate environment to meet the requirements of the fuel cell engine operation under various climate conditions, and also can provide required cooling medium to cool the engine.
All testing processes can be done under full automatic control, but at the same time, it also can be done under manual control. The two control modes can be easily converted to each other; all data can be automatically processed, saved and off-line queried. The experiment device can automatically control operating condition and data processing.
|
The highest power testing |
|
The highest thermal power |
|
The minimum stable power testing |
|
The highest temperature stable power testing |
|
The lowest temperature stable power testing |
|
Hydrogen consumption testing |
|
The winter testing |
|
Power calibration test |
|
Partial power testing |
|
Cold-start testing |
1. Temperature control parameters
range: -40℃～+50℃ Control precision: ±0.2℃
2. Humidity control parameters
range: relative humidity :10%R.H～95%R.H; Control precision :±5%R.H；
3. pressure in chamber control parameters
range: 0 ~ 2000 m pressure altitude siumlation
Control precision : ±50Pa.
(The above specifications are only for reference, it can be customized according to customer’s requirements)
